M2050 PRO Tester Kit

Extending the testing range to cover 0–50kN, the Hydrajaws M2050 PRO Tester kit enables engineers to validate the correct installation or establish the safe working loads of a comprehensive range of anchors and fixings in line with BS 8539 up to a maximum tensile load of 50kN.

M2050 Pro Kit Features

• 0-50kN Dual Scale rechargeable digital gauge (detachable for calibration, reduces carrier return costs).
• Load spreading bridge with adjustable multi-fix legs and precise height adjustable swivel feet.
• Turning Handle with 24mm (7/8″) integrated nut (for use in confined spaces).
• Hydrajaws gauge calibration certificate (valid for 12 months).
• The tester is preassembled and accessories can be quickly attached with ease.
• Each kit is supplied in a robust carry case.

Kit includes the following adaptors:

• M12 Ringbolt Adaptor Clevis.
• Bolt tester adaptor with M12 locking adaptor.
• M16, M20 & M24 Threaded stud adaptors.
• Six slotted button adaptors (mm): 4.5, 5.5, 6.5, 8.5, 10.5, 12.5.
• Two threaded button adaptors: M10, M12.
